Q: What is “PCI simple communication device” on the Device manager ?
A: It is virtual control port of Intel ME technology , you need to install the ME driver manually. The driver package is included with MEI & SOL devices driver.
Q: How to use three independent display output?
A: VGA and DVI share QM77 Display port 1 resource. DP.A uses QM77 Display port 2 and output High Res. Image. DP.B uses QM77 Display port 3 and output High Res. Image.
Q: I have created a RAID 1 array on ECS-7000-6R, how to check which SSD was broken while system is running? Is there have any alert LED or notes we could see?
A: ECS-7000 series offers standard data backup application, you can check it on RAID console screen or RST software on Windows 7.
Please note, Intel will update RST software for SSD devices support regularly. Please get it from Intel website. http://www.intel.com/p/en_US/support/highlights/sftwr-prod/imsm
Q: I have use a DVI to HDMI converter , but I cant get any sound output from my LCD TV. And I change to DP.A or DP.B , I cant get HDMI audio work find.
A: RCS-7000 is QM77 platform that supports three independent display ports with digital audio line. But the HDMI output needs additional codec support, you can find the codec on Chipset->PCH I/O Configuration -> PCH Azalia Configuration-> Azalia HDMI Codec Port B/C/D
ARS-1000 series is integrated with VGA display and LVDS output. These two display units are output synchronous. LVDS output needs additional hardware, such as LCD Panel, LVDS Cable, Backlight.
Q: I have connect four PoE Camera to PE-1004. I need to control external device by DIO port. How to use PE-1000 series' DIO Port in my application?
A: The DIO port of PE-1000 series is controlled by SMbus , please find the SMbus base address on the vice manager. Default device id is 0x40. And we reverse 3 jumps to adjust the device id.
