產品應用

RES-3000 (M12)

產品特色

    • 精巧型機身, IP67防護等級
    • 無風扇,支援-30°C 至70°C 作業環境
    • 第8代 Intel® Core™ i7/i5/i3 U-series 處理器 (Whiskey Lake)
    • 採用DDR4 2400MHz記憶體,最高支援32GB
    • Intel® UHD Graphics 620核心顯示器,支持DX 12、OpenGL 4.5與OpenCL 2.1
    • 2個乙太網路介面搭載超強固X-coded M12接頭,支持iAMT 12.0
    • 2個M12 RS-232/422/485串口,1個M12 2埠USB 2.0接頭
    • 支援9V 到48V寬範圍電壓輸入,採用M12防水接頭
    • 一站式設計與製造服務





    產品亮點

    IP67 Protection

    • Solid Particle Protection:Fully Dust Tight
    • Liquid Ingress Protection:Up to 1M depth in 30 minutes
    • Waterproof Chassis
    • Waterproof Connectors:DVI, GigE LAN, USB, COM, DC-in, Power Button





    Outstanding Performance

    • 8th Generation Intel Whiskey Lake Power-efficient Platform, max 15W TDP
    • Quad-core Intel Core i7/i5/i3 U-series SoC, max 32GB DDR4 Memory
    • More than 40% power productivity greater than former 7th Generation Intel Kaby Lake U-series processors
    • Intel UHD 620 graphics:4K resoluion, DirectX 12, OpenGL 4.5, OpenCL 2.1





    Compact Integratoion

    • Compact & Slim design
    • OpenVINO for AI Computing
    • DVI display, up to 4K Resolution
    • 2 GigE LAN, 2 COM RS-232/422/485, 2 USB
    • 1 2.5" SSD bracket, 1 SATA III, 1 mSATA
    • Smart Manageability:TPM 2.0, iAMT 12.0, PXE, Wake on LAN, Watchdog

    Rugged Reliability

    • Fanless -30°C to 70°C operation
    • 9V to 48V Wide Range DC Power Input
    • X-coded M12:GigE LAN
    • A-coded M12:COM, USB, DC-in
    • EN50155 & EN50121-3-2
    • Anti-shock, Anti-vibration
    • Industrial-grade Longevity



產品簡介

    IP67防護等級,優越的系統效能,多重強固型IP67等級M12防水接頭,支援乙太網路界面、串口RS-232/422/485、2埠USB介面、DC-in電源輸入介面,精巧型無風扇,支援-30°C 至70°C作業溫度,Vecow RES-3000系列IP67防護等級強固型嵌入式系統是您建構智慧工廠、軌道交通、機器人控制、智慧製造、智慧監控以及任何嚴苛環境中仍能維持系統正常運作的嵌入式解決方案。






產品規格

System
Processor Intel® Core™ i7/i5/i3/Celeron® U-series Processor (Whiskey Lake)
Chipset Intel® SoC (Cannon Lake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 2400MHz SO-DIMM, up to 32GB
OS Windows 10, Linux
I/O Interface
Serial  2 COM RS-232/422/485, A-coded M12 Connector
USB 1 supports 2-port USB 2.0, A-coded M12 Connector
LED Power, HDD
Graphics
Processor Intel® HD Graphics 620
Interface IP67 Waterproof DVI-D Connector, up to 1920 x 1200 @60Hz
Storage
SATA 1 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device
- 1 mSATA Socket
- 1 Internal 2.5" SSD/HDD Bracket
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0, X-coded M12 Connector
LAN 2 Intel® I210 GigE LAN, X-coded M12 Connector
Power
Power Input 9V to 48V, DC-in
Power Interface A-coded M12 Connector
Power Switch IP67 Waterproof Power Button
Others
TPM Optional Infineon SLB9665 supports TPM 2.0
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
Mechanical
Dimension (W x L x H) 250mm x 180mm x 44mm (9.8" x 7.1" x 1.7")
Weight 2.3 kg (5.07 lb)
Mounting
- Wallmount by mounting bracket
- VESA Mount
Environment
Operating Temperature -30°C to 70°C (-22°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 70°C
Shock
- IEC 60068-2-27
- SSD : 50G @ wallmount, Half-sine, 11ms
Vibration
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2



資源

產品 檔案內容 檔案類型 發佈日期 下載
RES-3000 (M12) RES-3000 DM (English) .PDF 2022/5/31 Download
RES-3000 (M12) RES-3000 DM (簡體中文) .PDF 2022/5/31 Download
RES-3000 (M12) RES-3000 カタログ (日本語) .PDF 2022/5/31 Download
RES-3000 (M12) RES-3000 User Manual .PDF 2023/6/2 Download
RES-3000 (M12) RES-3000 CE Certification .PDF 2020/3/25 Download
RES-3000 (M12) RES-3000 CE Test Report .PDF 2020/3/25 Download
RES-3000 (M12) RES-3000 FCC Certification .PDF 2020/3/25 Download
RES-3000 (M12) RES-3000 FCC Test Report .PDF 2020/3/25 Download
RES-3000 (M12) RES-3000 EN50155 & EN50121-3-2 Certification .PDF 2020/11/9 Download
RES-3000 (M12) RES-3000 EN50155 & EN50121-3-2 Test Report .PDF 2020/11/9 Download
RES-3000 (M12) RES-3000 Temperature Test & Shock and Vibration Test Report .PDF 2020/3/25 Download
RES-3000 (M12) RES-3000 EN60945 Certification .PDF 2020/5/26 Download
RES-3000 (M12) RES-3000 EN60945 Report .PDF 2020/5/26 Download

索取報價

產品型號 詳細內容 需求數量
RES-3000-8665U RES-3000, Intel® Core™ i7-8665UE, 2 GigE LAN, 2 COM, 2 USB 2.0
RES-3000-8365U RES-3000, Intel® Core™ i5-8365UE, 2 GigE LAN, 2 COM, 2 USB 2.0
RES-3000-8145U RES-3000, Intel® Core™ i3-8145UE, 2 GigE LAN, 2 COM, 2 USB 2.0
RES-3000-4305U RES-3000, Intel® Celeron® Processor 4305UE, 2 GigE LAN, 2 COM, 2 USB 2.0
DDR4 32G Certified DDR4 32GB 2666MHz RAM
DDR4 16G Certified DDR4 16GB 2666/2400/2133 MHz RAM
DDR4 8G Certified DDR4 8GB 2666/2400/2133 MHz RAM
DDR4 4G Certified DDR4 4GB 2666/2400/2133 MHz RAM
SATA HDD Certified 2.5" SATA HDD
SATA SSD Certified 2.5" SATA SSD
mSATA SSD Certified mSATA MLC SSD 64GB
IP67 Rated DVI Cable IP67 Rated DVI-D Cable, 200cm
IP67 Rated Ethernet Cable IP67 Rated M12 to RJ45 Ethernet Cable, 200cm
IP67 Rated COM Cable IP67 Rated M12 to COM Cable, 200cm
PWA-120W 120W, 24V, 90V AC to 264V AC Power Adapter with 3-pin Terminal Block
