ESOM-MT-1200

Features

    • Octa-core MediaTek Genio 1200 processor with quad Cortex-A78 and quad Cortex-A55, 4.8 AI TOPS
    • Integrated Mali-G57 GPU and H.265/H.264 4K video decoding
    • Onboard 8GB LPDDR4X memory and 64GB eMMC
    • Support 3 4-lane MIPI CSI-2 camera with internal ISP for dual 16MP
    • Support 2 Digital Display, 2 DP and 2 4-lane MIPI DSI, 4K resolution
    • Supports 1 PCIe x2, 2 USB 3.0, 1 Gigabit Ethernet
    • Supports Android 11 and Yocto 3.1 operating system

Overview

    Vecow ESOM-MT-1200 features MediaTek Genio 1200 that integrates Octa-core processor with Quad Cortex-A78 and Quad Cortex-A55, AI accelerator with 4.8 TOPS performance. The ESOM-MT-1200 provides a powerful and efficient performance designed for premium AIoT applications. The ESOM-MT-1200 supports 8GB LPDDR4X RAM, 64GB eMMC, multiple high-speed interfaces, and a powerful Mali-G57 GPU. Both Android 11 and Yocto 3.1 operating systems are supported for upgradeability and scalability.



Specifications

System
Processor
MediaTek Genio 1200 Processor with Quad-core
Cortex-A78 @2.2GHz and Quad Cortex-A55 @2.2GHz
Memory 8GB LPDDR4X SDRAM
eMMC 64GB eMMC
OS ・Android 11
・Linux Yocto 3.1
I/O Interface
Internal I/O  4 board to board Connector
Graphics
Graphics
Processor
・ARM Mali-G57 high-performance GPU
・3D graphics accelerator capable of processing 17600M pixel/sec @ 880MHz
・Graphics engine supporting OpenGL® ES 3.2, OpenCL 2.2, and Vulkan 1.1 hardware acceleration
Video
・Video Encode:
 - HEVC: 4K2K@60fps
  - H.264: 4K2K@60fps
・Video Decode:
 - HEVC: 4K2K@90fps
  - H.264: 4K2K@90fps
Display
・Supports dual independent display:
・1 Digital Display TX : 4096 x 2160 @60Hz
・1 Digital Display RX : 4096 x 2160 @60Hz
・2 DisplayPort TX : 4096 x 2160 @60Hz
・2 MIPI DSI : 3840 x 2160
Camera
・Three 4-lane MIPI CSI-2
・Integrated image signal processor supports single 48MP @30fps or dual 16MP @30fps
Ethernet
LAN 10/100/1000 Mbps Ethernet LAN by Microchip LAN7800
Audio
Audio Codec  MediaTek MT6365
Audio Interface Mic-in, Line-out
Expansion
PCIe 1 PCIe Gen3 x2
USB
・1 USB 3.0
・2 USB 2.0
UART
・1 4-wire UART
・3 2-wire UART
SDIO 1 SDIO
SPI 2 SPI
I2C 2 I2C
I2S 1 I2S (In and Out)
DMIC 2 DMIC
PWM 2 PWM
AUXADC 6 AUXADC
GPIO 8 GPIO
Power
Power Input 4.2V DC-in
Mechanical
Dimensions 82 mm x 55 mm
Environment
Operating
Temperature
-20°C to 85°C
Storage
Temperature
-40°C to 85°C
Humidity 5% to 95% Humidity, Non-condensing
Relative
Humidity
95% at 85°C
EMC CE, FCC



Resources

Item File Name Format File Update Download
ESOM-MT-1200 ESOM-MT-1200 Datasheet .PDF 2022/8/5 Download
ESOM-MT-1200 ESOM-MT-1200-CB Datasheet .PDF 2022/6/20 Download

Inquiry

Product Description Qty
ESOM-MT 1200 System on Module with MediaTek Genio 1200 octa-core Processor, 8GB LPDDR4 SDRAM, 64GB eMMC
